Bat_terminal_caps_1

To protect battery termnals from shorting, descision was made to fabricate custom fiberglass covers. Here you see round head carriage bolts screwed to 1/8" Balsa, wrapped with some masking tape to build up dimensions a bit and then covered with two layers of Saran wrap.
Y9-01-17

Date: 01/16/2009
