Annunciator sketch angle 1

Idea at moment is to install a Europa sketch in ceiling panel with LEDs to act as an annunciator. In order to be readable, front needs to be lower than aft portion of sketch. Thus a 6" x 6" piece of real estate is what I have to work with.
Y10-02-24

Date: 02/24/2010
