EuropaOwners A-265 - (XS-FUN) - N4211W / Wayne Gutschow+Ron Parigoris Top fuse bond on information and "ProgMess". Voids in fuse seam while installing Ultimate ventilators. Nose up attitude.
Advanced Search
View Slideshow (Fullscreen)

Voids in fuse seam while installing Ultimate ventilators.

1. Nose up... 2. Top bond on... 3. Ultimate... 4. Ultimate... 5. Ultimate... 6. Ultimate... 7. Ultimate... ... 15. Ultimate...

Random Images

P9010094

P9010094

Date: 09/01/2007 Views: 4946

110602_airscoop

110602_airscoop

Date: 01/17/2006 Views: 5692

FirewallBlanket04Ann

FirewallBlanket04Ann

Date: 09/05/2005 Views: 3517

Newest Image

EAA SITE

EAA SITE

Date: 08/23/2023 Views: 695273

Nose up attitude.

Picts and info how fuse seam was reinforced where there were voids and just how little adhesion there is when injecting Redux into voids after initial bond cures.
Builders noses were a little too high thinking job of bonding on top was done well after inspecting with bright light from inside out, and outside in after getting a good squeeze out on top and bottom of seam. Even after discovery of voids, lights or tapping a quarter did not tell story. Wetting out both sides fools light, and stalagtightes and stalagmites fool coin tap. The best accessment is only very dark areas have proper bond.
Lighter areas could just be that things are squeezed tighter, or they are voids. Tapping does not tell story.
Drilling holes in lighter areas and trying to inject Redux tells you what you want to know, if some Redux can be injected and color darkens there are voids.
Y9-07-11

Date: 07/11/2009
Size:
Full size: 3008x2000
nextlast
Nose up attitude.
